delphi中TListView控件使用

要点:

1.代码备注的超级详细，如下:

unit Unit1;

interface

uses

Windows, Messages, SysUtils, Variants, Classes, Graphics, Controls, Forms,

Dialogs, StdCtrls, ComCtrls;

type

TForm1 = class(TForm)

lv1: TListView;

Button1: TButton;

Button2: TButton;

Button3: TButton;

Button4: TButton;

Button5: TButton;

Button6: TButton;

Button7: TButton;

Button8: TButton;

Button9: TButton;

procedure Button1Click(Sender: TObject);

procedure Button2Click(Sender: TObject);

procedure Button3Click(Sender: TObject);

procedure Button4Click(Sender: TObject);

procedure Button5Click(Sender: TObject);

procedure Button6Click(Sender: TObject);

procedure Button7Click(Sender: TObject);

procedure lv1CustomDrawItem(Sender: TCustomListView; Item: TListItem;

State: TCustomDrawState; var DefaultDraw: Boolean);

procedure lv1ColumnClick(Sender: TObject; Column: TListColumn);

procedure FormCreate(Sender: TObject);

procedure Button8Click(Sender: TObject);

procedure Button9Click(Sender: TObject);

private

public

procedure 分组(Sender: TObject);

end;

var

Form1: TForm1;

implementation

{$R *.dfm}

{风格}

procedure TForm1.Button1Click(Sender: TObject);

begin

lv1.Clear; //清空

lv1.Columns.Clear;

//lv1.ViewStyle := lv1

{增加3项列表头}

lv1.Columns.Add;

lv1.Columns.Items[0].Caption:='时间';

lv1.Columns.Items[1].Caption:='地点';

lv1.Columns.Items[2].Caption:='人物';

lv1.Columns.Items[0].Width:=100;

lv1.Columns.Items[1].Width:=100;

lv1.Columns.Items[2].Width:=300;

{设置属性}

lv1.ViewStyle:=vsreport; //报表模式

lv1.GridLines:=true; //表格线

//lv1.RowSelect := True; //选中一整行

end;

{}

{插入数据方法1}

procedure TForm1.Button2Click(Sender: TObject);

begin

with lv1.items.add do

begin

caption:='2013';

subitems.add('上海');

subitems.add('田攀');

end;

{插入数据方法2}

procedure TForm1.Button3Click(Sender: TObject);

var

Titem:Tlistitem;//存储临时记录.

begin

Titem := lv1.Items.add;

Titem.Caption := '201314';

Titem.SubItems.Add('广州');

Titem.SubItems.Add('God');

end;

{删除行}

procedure TForm1.Button4Click(Sender: TObject);

begin

lv1.DeleteSelected; //删除选中行

lv1.Items.Item[2].Delete;//删除某一行

lv1.Items.Clear;//清除所有数据

end;

{按标题内容删除}

procedure TForm1.Button6Click(Sender: TObject);

var

I: Integer;

begin

for I := 0 to lv1.Items.Count - 1 do

begin

if lv1.Items[I].Caption = '田攀2013' then //如果标题为 '田攀2013'

lv1.Items.Item[I].Delete();//删掉

end;

{选择某行}

procedure TForm1.Button7Click(Sender: TObject);

begin

lv1.SetFocus;//获取焦点

lv1.Items[lv1.Items.Count - 1].Selected := True;//选中

end;

procedure TForm1.Button8Click(Sender: TObject);

begin

分组(Sender);

end;

{分组效果}

procedure TForm1.分组(Sender: TObject);

begin

with lv1 do

begin

AllocBy := 0; //设置总共的项数量，省去每次添加开辟内存空间

Checkboxes := False; //项左边出现复选框，vsList or vsReport有效

Color := clWindow; //背景颜色

ColumnClick := True; //列头能否点击

with Columns.Add do //增加列

begin

Alignment := taLeftJustify; //左对齐

Caption := '田攀';

ImageIndex := -1;

Width := 100;

end;

with Columns.Add do //增加列

begin

Caption := '2013';

ImageIndex := -1;

Width := 50;

end;

Ctl3D := True;

DoubleBuffered := False; //双缓冲

Enabled := True;

FlatScrollBars := False; //平滑滚动条

FullDrag := False; //允许拖动列头

GridLines := False; //表格线

GroupHeaderImages := nil; //分组头关联图像列表

with Groups.Add do //增加分组

begin

BottomDescription := '说明文字';

ExtendedImage := -1; //关联 GroupHeaderImages图像列表，only on Windows Vista

Footer := '页脚文本';

FooterAlign := taLeftJustify; //页脚文本对齐

GroupID := 0; //组ID号

Header := '页首文本';

HeaderAlign := taLeftJustify;

State := [ //分组状态，一些状态只应用于VISTA系统

lgsNormal, //所有分组展开

lgsHidden, //分组隐藏

lgsCollapsed, //分组折叠 Windows Vista only.

lgsNoHeader, //页首不可见 Windows Vista only.

lgsCollapsible, //分组可折叠 Windows Vista only.

lgsFocused, //分组有键盘焦点 Windows Vista only.

lgsSelected, //分组被选择 Windows Vista only.

lgsSubseted, //只有分组的一个子集显示出来 Windows Vista only.

lgsSubSetLinkFocused //分组的子集有键盘焦点 Windows Vista only.

];

SubsetTitle := '子集标题';

Subtitle := '子标题';

TitleImage := -1; //关联 GroupHeaderImages图像列表，only on Windows Vista

TopDescription := '顶部的说明文字';

end;

with Groups.Add do

begin

GroupID := 1;

Header := '分组标题';

end;

GroupView := True; //打开或关闭分组视图

HideSelection := True; //失去焦点时，项不再保持被选择状态

HotTrack := False; //指定是否鼠标移过项进行高亮

HotTrackStyles := [

// htHandPoint, //手势

// htUnderlineCold, //非热点下划线

// htUnderlineHot //下划线热点

];

HoverTime := -1; //鼠标在项上暂停时间，除非HotTrack为True

with IconOptions do //确定如何排列图标，vsIcon or vsSmallIcons 有效

begin

Arrangement := iaTop; //项在顶部从左到右对齐，iaLeft在左部从上到下对齐

AutoArrange := False; //图标自动重新排列

WrapText := True; //图标标题是否折行

end;

with Items.Add do //增加项

begin

Caption := '张三';

ImageIndex := -1; //关联 LargeImages or SmallImages图像列表

StateIndex := -1; //关联StateImages图像列表

GroupID := 0; //关联分组ID号

SubItems.Add('广州'); //添加第二列

end;

with Items.Add do

begin

Caption := '李四';

GroupID := 1;

SubItems.Add('上海');

end;

LargeImages := nil; //大图标图像列表

MultiSelect := False; //多选

OwnerData := False; //指定列表视图控件是否是虚拟的

OwnerDraw := False; //自绘项

ParentColor := False; //继承父控件颜色

ReadOnly := False; //只读

RowSelect := False; //整行选择

ShowColumnHeaders := True; //显示列头，vsReport有效

ShowWorkAreas := False; //显示工作区，vsIcon or vsSmallIcon有效，不支持 OwnerData

SmallImages := nil; //小图标图像列表

SortType := stNone; //确定列表项如何自动排序

StateImages := nil; //状态图像列表

ViewStyle := vsReport; //视图风格，vsIcon、vsSmallIcon、vsList、vsReport

end;

{初始化，TList分组}

procedure TForm1.FormCreate(Sender: TObject);

begin

end;

{显示和隐藏列表头}

procedure TForm1.Button9Click(Sender: TObject);

var

IsShow : Boolean;

begin

IsShow := lv1.ShowColumnHeaders;//是否隐藏列表头

lv1.ShowColumnHeaders := not IsShow;//取反

end;

{每2行交叉换颜色}

procedure TForm1.lv1CustomDrawItem(Sender: TCustomListView; Item: TListItem;

State: TCustomDrawState; var DefaultDraw: Boolean);

begin

if Item.Index mod 2 = 0 then//如果序号是2的倍数

Sender.Canvas.Brush.Color :=clSkyBlue //蓝色

else

Sender.Canvas.Brush.Color :=clWhite; //白色

end;

{读取数据}

procedure TForm1.Button5Click(Sender: TObject);

begin

ShowMessage(lv1.Items[2].Caption) ; //读取某条数据标题

ShowMessage(lv1.Items[2].SubItems.strings[1]) ;//读取第二行的第二子列（也就是第三列）

ShowMessage(lv1.Items[2].SubItems.CommaText); //显示全部内容

end;

{排列函数}

function CustomSortProc(Item1, Item2: TListItem; ColumnIndex: integer): integer; stdcall;

begin

if ColumnIndex = 0 then //第0行

Result := CompareText(Item1.Caption,Item2.Caption) //返回

else

Result := CompareText(Item1.SubItems[ColumnIndex-1],Item2.SubItems[ColumnIndex-1]);

end;

{点击每列头重新排列列表}

procedure TForm1.lv1ColumnClick(Sender: TObject; Column: TListColumn);

begin

lv1.CustomSort(@CustomSortProc,Column.Index); //点击每行第一个排列

end;

end.

https://www.cnblogs.com/GodPan/p/3391193.html
